WiFi relej za upravljanje RGBW trakom – 2x
Availability:
1 na zalihi
U paketu se nalaze 2 releja
| Power supply AC | No |
|---|---|
| Power supply DC | 12 – 24V |
| DC Power Output 12V per channel | 45W |
| DC Power Output 24V per channel | 90W |
| DC Power Output 12V combined power | 144W |
| DC Power Output 24V combined power | 288W |
| Device temperature protection | No |
| Overload protection | No |
| Power measurement | Yes |
| Dimming | Yes |
| Working without a neutral line | No |
| Colour changing | Yes |
| Predefined effects | Yes |
| Channels | 4 Channel |
| Maximum load | 12A |
| Operational temperature | 0ºC to +50ºC |
| Device power consumption | < 1 W |
| Intelligent On/Off | Yes |
| Local and remote control | Yes |
| Sunrise/Sunset | Yes |
| Weekly Schedule | Yes |
| UL Listed option | No |
| Wireless/WiFi Protocol | 802.11 b/g/n |
| Radiofrequency | 2400 – 2484 MHz |
| Radio signal power | 1mW |
| Range | up to 50 m outdoors and up to 30 m indoors (depending on the building materials) |
| Size | 43mm x 38mm x 14mm |
| Pakiranje | x1, x2 |
70,00 €
1 na zalihi
UsporediWiFi RGBW upravljač
- Upravljajte svojom RGBW trakom s mobitela ili putem asistenta
- Shelly RGBW povezuje se poput bilo kojeg LED kontrolera.
- Podržavaju bilo koje bijele, RGB, RGBW trake, i 12/24v žarulje, kombinirane snage do 288W.
- Glavna je prednost što ćete svjetlost moći kontrolirati bez potrebe za dodatnim daljinskim upravljačem.
| Proizvođač | Shelly |
|---|
